Agitador de alta velocidad / mezclador dividido

Inicio > Productos > Agitador superior > Agitador de alta velocidad / mezclador dividido >

Agitador con alta velocidad y alto par

Cantidad máxima de agitación :40(L) H2O

Model: WB1800-D

Order NO.: 100600

3004

Specific parameters will be adjusted according to product upgrades, without notice.

Quotation Request

PRODUCT OVERVIEW

Description



Specifications

Please note that other overhead stirrer models are available on request, please contact wiggens for further information.

Model

WB1800-D

Display / Control Mode

TFT Digital Display /On-Touch Control

Speed Accuracy (rpm)

± 1rpm

Torque display

Stirrer converts output current to torque, reflecting the changing load of motor

Speed Range (rpm)

Low: 20~360

High: 361~1800

Torque (N-cm)

Low: 563

High: 113

Maximum Viscosity (cps)

150000

Maximum Torque (N-cm)

563

Chuck range max. diameter (mm)

10

Maximum Capacity (L) H2O

40

Output Power (W)

150

Dimensions (W × L × H in mm)

200x95x230

Motor Weight (Kg)

5

Order No.

100600

Order Information
additional order no.: WBXX00-D-P1,P2 and P3



Accessories
